1/3,1725,DP,48Z,1/60/115/230
No. of Poles
4
Motor Type
Capacitor Start Induction Run
Enclosure
Drip Proof
HP (Max.)
1/3
Voltage
115/208-230
Mounting
Resilient Base/Extended Studs
Speeds
1
Hz
60
Rotation
Selective CCW
RPM Range
1725
NEMA Frame Size
48Z
Phase
Single
Standards
UL/CSA
FLA
5.8/3.1-2.9
Bearing
Ball
Thermal Protection
Auto
Ambient Deg C
40
NOTE
Horizontal Motor Orientation
Ins. Class
B
Shaft Dia. (in.)
1/2
Capacitor Included
Yes
Shaft Length (in.)
1.97
Service Factor
1.35
Duty
Continuous
Item #:
B315
Marathon Fan & Blower Motor
- Automatic reset thermal protection prevents overheating
- Patented MAXGuard® insulation system offers superior protection for use with a variable frequency drive
- Permanently lubricated, double-sealed bearings extend the lifetime of the motor
- Vertical/horizontal mounting for proper placement of the fan within airflow
- Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications
