Whisper quiet with multiple modes and 24-hour timer Artic white exterior and low profile head blend with any décor Power comes from the outdoor section so there are no cords to hide
MINISPLIT HP INVERTER SGL ZONE
30K R410A INDOOR UNIT 230V
Detail
30K High Wall Mount
Refrigerant
R410A
EER
9.40
Conductor AWG
14G 4 Wire Stranded
Voltage
208/230V-1-60
SEER/HSPF
19.80/11.50
Cooling Capacity BTUH
30,000
Inverter Technology
Yes
Heating Capacity BTUH
30,000
Wireless Remote
Yes
Low Ambient Operation
5°F
Operating Temperature
5° to 122°F cooling, 5° to 86°F heating
Warranty
6 years on compressor, 5 year on parts
CFM
677
Fan Speeds
3
Auto Restart
Yes
Modes
Cooling, heating, dehumidification, fan only
Sound Rating (dBA)
49/42/37.5
Dimensions HxWxD (in.)
13.5x46.625x10.125
Shipping Wt (lbs)
50.2
Test Listing
ETL US and Canada
Certification
AHRI (complete system)
Item #:
B-VMH30SD-1-CY
