Home  >  Motors  >  OEM Replacement  >  More OEM Replacements  > Blower,115V,Sp.1

Blower,115V,Sp.1

Motor Type Draft Inducer/Shaded Pole Enclosure Open HP (Max.) 1/35 Voltage 115 Mounting Flange Speeds 1 Hz 60 Rotation CW RPM Range 3000 NEMA Frame Size C Frame Phase Single Standards UL/CSA FLA 1.6 Bearing Ball Thermal Protection Thermally Ambient Deg C 40 Ins. Class B Replaces 7002-2792, 1010975P Duty Air Over
Item #: A172
Blower,115V,Sp.1

OEM Direct Replacement - Draft Inducer Blower

  • C-Frame
  • Shaded Pole
  • Thermally Protected
  • Open Air Over
  • Class B Insulation, 40°C Ambient
  • Ball Bearing

    • Motors

    Motor Type
    Draft Inducer/Shaded Pole
    Enclosure
    Open
    HP (Max.)
    1/35
    Voltage
    115
    Mounting
    Flange
    Speeds
    1
    Hz
    60
    Rotation
    CW
    RPM Range
    3000
    NEMA Frame Size
    C Frame
    Phase
    Single
    Standards
    UL/CSA
    FLA
    1.6
    Bearing
    Ball
    Thermal Protection
    Thermally
    Ambient Deg C
    40
    Ins. Class
    B
    Replaces
    7002-2792, 1010975P
    Duty
    Air Over
