Home  >  Motors  >  HVAC  >  Condenser Fan  > 1-1/2HP 1140RPM 208-230/460

1-1/2HP 1140RPM 208-230/460

Motor Type Three Phase Enclosure OPAO HP (Max.) 1-1/2 Voltage 208-230/460 Mounting Belly Band, Resilient Ring Speeds 1 Hz 60/50 Rotation REV RPM Range 1140 NEMA Frame Size 56Y Phase Three Standards CUL FLA 5.3-5.09/2.55 Bearing Ball Thermal Protection Auto Ambient Deg C 70 Ins. Class H1 Shaft Dia. (in.) 5/8 Capacitor Included No Shaft Length (in.) 5.0 Replaces H1051A, CFM3166A, 1819H, D6610, H767, X503 Service Factor 1.0 Duty Continuous
Item #: 10503

MARS Commercial Condenser Fan Motor

  • VFD Compatible, except 575V
  • Water slinger on shaft
  • Enclosed shaft end bracket, vented frame
  • Use on Trane, Carrier, Cimaterol and York units, 5 tons and larger
  • Flat and keyway on shaft
  • Belly Band and Resilient Ring Mounting
  • 70C Ambient
  • Automatic Thermal Overload
  • Continuous duty, air over

    • Motors

    Motor Type
    Three Phase
    Enclosure
    OPAO
    HP (Max.)
    1-1/2
    Voltage
    208-230/460
    Mounting
    Belly Band, Resilient Ring
    Speeds
    1
    Hz
    60/50
    Rotation
    REV
    RPM Range
    1140
    NEMA Frame Size
    56Y
    Phase
    Three
    Standards
    CUL
    FLA
    5.3-5.09/2.55
    Bearing
    Ball
    Thermal Protection
    Auto
    Ambient Deg C
    70
    Ins. Class
    H1
    Shaft Dia. (in.)
    5/8
    Capacitor Included
    No
    Shaft Length (in.)
    5.0
    Replaces
    H1051A, CFM3166A, 1819H, D6610, H767, X503
    Service Factor
    1.0
    Duty
    Continuous
    MFG NameMFG #
    BaldorCFM3166A
    Century/AO SmithH1051A
    US Motors/Emerson1819H
    FascoD6610
    MagnetekH767
    MarathonX503

    Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
