Home  >  Comfort-Aire  >  Geothermal/Residential  >  Flush Carts  > FLUSH CART 2HP 115V TLO

FLUSH CART 2HP 115V TLO

Detail 2 HP Flush Cart Diameter (in.) 1-1/4 Amp Rating 20 Voltage/Phase/Hz 115V-1-60 Hose Length (ft.) 10 Flow Rate 122 gpm max. Mounting On a heavy duty cart Temp. Limit (F) 400 max. Rotation Clockwise from drive end Max. (psi) 200 Material Stainless steel 14 gauge Pipe Size (in.) 1-1/4 Dimensions HxWxD (in.) 53x22.5x0 Shipping Wt (lbs) 196 NOTE Flush cart used to fill, flush & purge geo. loops
Item #: 7602-401
FLUSH CART 2HP 115V

Power-Flow Purge Carts

  • Cart material is mild steel
  • Tank material is 304L SS,14 gauge
  • Valves are yellow brass
  • Valve size is 1-1/4"
  • Hose rated for 150 psi
  • Hose connection 1-1/4" cam and groove
  • Tank volume is 10 US gallons
  • Double woven screen filter located in tank

    • Flush Carts

    Detail
    2 HP Flush Cart
    Diameter (in.)
    1-1/4
    Amp Rating
    20
    Voltage/Phase/Hz
    115V-1-60
    Hose Length (ft.)
    10
    Flow Rate
    122 gpm max.
    Mounting
    On a heavy duty cart
    Temp. Limit (F)
    400 max.
    Rotation
    Clockwise from drive end
    Max. (psi)
    200
    Material
    Stainless steel 14 gauge
    Pipe Size (in.)
    1-1/4
    Dimensions HxWxD (in.)
    53x22.5x0
    Shipping Wt (lbs)
    196
    NOTE
    Flush cart used to fill, flush & purge geo. loops
