Home  >  HVAC/R Components  >  Contactors  >  MARS 780 Contactors  > 2P 40A 277V QC & BL A2L

2P 40A 277V QC & BL A2L

Contactor Type Definite Purpose No. of Poles 2 FLA Inductive 40 FLA Resistive 50 Coil Voltage 277 A2L Compliance A2L Compliant Lug or Screw Terminal Box Lugs Standards UL Coil Hz. 50/60
Item #: 62758
2P 40A 277V QC & BL A2L
  • Designed for use on refrigeration, air conditioning and electric heating systems
  • Engineered for today's most demanding commercial refrigeration and HVAC applications
  • Enclosed body provides a quieter running contactor and a longer life expectanc
  • Oversized Arch Window to simplify wiring
  • High Performance Copper & Brass Conductors maximize current carrying capability creating a cooler running contactor
  • Multi-purpose Coil Terminals allow the use of QC terminals or stripped wires
  • Removable Coils allow field replacement of damaged coils
  • Removable Cover provides full access to the contacts
  • Thermoplastic Housing resists dusting and contamination of the contacts to maintain maximum conductivity
  • A2L Compliant design

    • Contactors

    Contactor Type
    Definite Purpose
    No. of Poles
    2
    FLA Inductive
    40
    FLA Resistive
    50
    Coil Voltage
    277
    A2L Compliance
    A2L Compliant
    Lug or Screw Terminal
    Box Lugs
    Standards
    UL
    Coil Hz.
    50/60
