Home  >  HVAC/R Components  >  Fan Blades  >  Accessories  > Variable Pitch Pulleys

Variable Pitch Pulleys

CSA 03534 4.75" Dia 7/8" Bore
Diameter (in.) 4.75 Type Variable Pitch Pulley Use With V-Belt B, 3L, 4L, 5L, A Bore Diameter (in.) 7/8 Mounting 3/16x3/32 Length (in.) 11/16 to 1-1/16 No. of Grooves 1 Face Width (in.) 11/16 to 1-1/16 Function 7/8 Keyway Size 3/16x3/32 Length thru Bore (in.) 1.9375 Composition Cast Iron NOTE With Keyway
Item #: 40844
Variable Pitch Pull
  • Prevents slippage and misalignment
  • Use with V-belts to transfer motion from motors to belts, fans, and pumps
  • Provides maximum friction and torque

    • Fan blade Accessories

    Diameter (in.)
    4.75
    Type
    Variable Pitch Pulley
    Use With
    V-Belt B, 3L, 4L, 5L, A
    Bore Diameter (in.)
    7/8
    Mounting
    3/16x3/32
    Length (in.)
    11/16 to 1-1/16
    No. of Grooves
    1
    Face Width (in.)
    11/16 to 1-1/16
    Function
    7/8
    Keyway Size
    3/16x3/32
    Length thru Bore (in.)
    1.9375
    Composition
    Cast Iron
    NOTE
    With Keyway
