Prevents slippage and misalignment Use with V-belts to transfer motion from motors to belts, fans, and pumps Provides maximum friction and torque
Variable Pitch Pulleys
4.15x1-1/8 Cast Irn, Varbl
Diameter (in.)
4.15
Type
Variable Pitch Pulley
Use With
V-Belt B, 3L, 4L, 5L, A
Bore Diameter (in.)
1-1/8
Length (in.)
21/32 to 1-1/32
No. of Grooves
1
Face Width (in.)
21/32 to 1-1/32
Function
1-1/8
Keyway Size
Cast Iron
Length thru Bore (in.)
2.156
Composition
Cast Iron
Min. Pitch Dia. (in.)
2.7
Max. Pitch Dia (in.)
3.5
Item #:
40842
