Home  >  HVAC/R Components  >  Fan Blades  >  Accessories  > Variable Pitch Pulleys

Variable Pitch Pulleys

CSA 03562 2.5" Dia 5/8" Bore
Diameter (in.) 2.5 Type Variable Pitch Pulley Use With V-Belt 3L Bore Diameter (in.) 5/8 Mounting 3/16x3/32 Length (in.) 17/32 to 25/32 No. of Grooves 1 Face Width (in.) 17/32 to 25/32 Function 5/8 Keyway Size 3/16x3/32 Length thru Bore (in.) 1.6875 Composition Cast Iron Min. Pitch Dia. (in.) 1.6 Max. Pitch Dia (in.) 2.4 NOTE With Keyway
Item #: 40830
Variable Pitch Pull
  • Prevents slippage and misalignment
  • Use with V-belts to transfer motion from motors to belts, fans, and pumps
  • Provides maximum friction and torque

    • Fan blade Accessories

    Diameter (in.)
    2.5
    Type
    Variable Pitch Pulley
    Use With
    V-Belt 3L
    Bore Diameter (in.)
    5/8
    Mounting
    3/16x3/32
    Length (in.)
    17/32 to 25/32
    No. of Grooves
    1
    Face Width (in.)
    17/32 to 25/32
    Function
    5/8
    Keyway Size
    3/16x3/32
    Length thru Bore (in.)
    1.6875
    Composition
    Cast Iron
    Min. Pitch Dia. (in.)
    1.6
    Max. Pitch Dia (in.)
    2.4
    NOTE
    With Keyway
