Home
>
Motors
>
HVAC
>
Oil Burner
> 1/2HP 115/230 3450 RPM
1/2HP 115/230 3450 RPM
OIL BURNER MOTOR
Motor Type
PSC
Enclosure
Semi Enclosed
H.P. (Max.)
1/2
Voltage
115/208-230
Speeds
1
Hz
60
Rotation
REV
RPM Range
3450
NEMA Frame Size
48N
Phase
Single
Standards
cULus
FLA
0.20/4.1
Mount
Two bolt direct mounting
Bearing
Ball
Shaft Length Inches
1.75
Shaft Dia Inches
1/2
Thermal Protection
Auto
Ambient Deg C
40
Ins. Class
Class B
Capacitor Included
No
Item #:
30011
Motors
Motor Type
PSC
Enclosure
Semi Enclosed
H.P. (Max.)
1/2
Voltage
115/208-230
Speeds
1
Hz
60
Rotation
REV
RPM Range
3450
NEMA Frame Size
48N
Phase
Single
Standards
cULus
FLA
0.20/4.1
Mount
Two bolt direct mounting
Bearing
Ball
Shaft Length Inches
1.75
Shaft Dia Inches
1/2
Thermal Protection
Auto
Ambient Deg C
40
Ins. Class
Class B
Capacitor Included
No
MFG Name | MFG # |
US Motors/Emerson | 3267 |
Marathon | O011 |
Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
