Home  >  JARD  >  JARD Motors  >  JARD Direct Drive  > 3/4HP 115V 1075RPM 3SP REV

3/4HP 115V 1075RPM 3SP REV

No. of Poles 6 Motor Type PSC Enclosure OAO HP (Max.) 3/4 Voltage 115 Mounting Belly Band, Resilient Ring Speeds 3 Hz 60 Rotation REV RPM Range 1075 NEMA Frame Size 48 Phase Single Standards CUL FLA 11.2 Bearing Ball Lead Length (in.) 32 Thermal Protection Auto Ambient Deg C 40 Ins. Class B Shaft Dia. (in.) 1/2 Capacitor Included No Shaft Length (in.) 4.5 Capacitor Rating 15/370 Service Factor 1.0 Duty Continuous
Item #: 22589
3/4HP 115V 1075RPM

JARD Direct Drive Blower Motors

  • Rheem mounting holes
  • Extended thru bolts shaft end
  • 3 Speed, Single Phase
  • Sleeve Bearing
  • Capacitor required: 15 MFD 370V
  • (2)2-1/4 & (2)2-1/2 Resilient Rings
  • Thermal protected, air over
  • 30 in. Leads

    • Motors

    No. of Poles
    6
    Motor Type
    PSC
    Enclosure
    OAO
    HP (Max.)
    3/4
    Voltage
    115
    Mounting
    Belly Band, Resilient Ring
    Speeds
    3
    Hz
    60
    Rotation
    REV
    RPM Range
    1075
    NEMA Frame Size
    48
    Phase
    Single
    Standards
    CUL
    FLA
    11.2
    Bearing
    Ball
    Lead Length (in.)
    32
    Thermal Protection
    Auto
    Ambient Deg C
    40
    Ins. Class
    B
    Shaft Dia. (in.)
    1/2
    Capacitor Included
    No
    Shaft Length (in.)
    4.5
    Capacitor Rating
    15/370
    Service Factor
    1.0
    Duty
    Continuous
    MFG NameMFG #
    Carrier/TotalineP257-8589
    Century/AO SmithDL1076
    EconomasterEM3589
    FascoD728
    GE/Genteq3589
    Magnetek0678
    MarathonX009
    Nordyne/ Partners Choice01-0172
    Packard43589
    Rheem/ProtechW51-34BAA3-01
    ROTOMDD-3589
    Smart ElectricSE3589
    US Motors/Emerson8904
    WagnerWG840589
    York/Source 7S1-FHM3589

    Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.

    ©MOTORS & ARMATURES, INC.
    MFG NameMFG #
    MARS10589
    MARS Azure10866

    Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
