Home
>
Motors
>
HVAC
>
Draft Inducer
> TRANE 80% D965130P01
TRANE 80% D965130P01
Motor Type
PSC
Enclosure
Open
H.P. (Max.)
15W-19Watt
Voltage
208-230
Multi-Rated H.P.
15W-19Watt
Speeds
2
Hz
60
Rotation
CW
RPM Range
2800
NEMA Frame Size
2.6"/65mm
Phase
Single
Standards
CUL
FLA
0.22
Bearing
Ball
Shaft Length Inches
4.32
Shaft Dia Inches
0.3
Thermal Protection
BR-A1D150
Ambient Deg C
60
Ins. Class
Class F
Capacitor Included
Yes
Capacitor Rating
2/370V
Item #:
10563
Motors
Motor Type
PSC
Enclosure
Open
H.P. (Max.)
15W-19Watt
Voltage
208-230
Multi-Rated H.P.
15W-19Watt
Speeds
2
Hz
60
Rotation
CW
RPM Range
2800
NEMA Frame Size
2.6"/65mm
Phase
Single
Standards
CUL
FLA
0.22
Bearing
Ball
Shaft Length Inches
4.32
Shaft Dia Inches
0.3
Thermal Protection
BR-A1D150
Ambient Deg C
60
Ins. Class
Class F
Capacitor Included
Yes
Capacitor Rating
2/370V
MFG Name | MFG # |
Trane | D965130P01 |
Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
