> NORDYNE 90% 622302
NORDYNE 90% 622302
Motor Type
PSC
Enclosure
Open
H.P. (Max.)
1/31
Voltage
115
Speeds
1
Hz
60
Rotation
CW
RPM Range
3300
NEMA Frame Size
2.6"/65mm
Phase
Single
Standards
CUL
FLA
0.46
Bearing
Ball
Shaft Length Inches
4.06
Shaft Dia Inches
0.3
Thermal Protection
BR-A1D130
Ambient Deg C
60
Ins. Class
Class B
Capacitor Included
Yes
Capacitor Rating
6/250V
Item #:
10558
Motors
Motor Type
PSC
Enclosure
Open
H.P. (Max.)
1/31
Voltage
115
Speeds
1
Hz
60
Rotation
CW
RPM Range
3300
NEMA Frame Size
2.6"/65mm
Phase
Single
Standards
CUL
FLA
0.46
Bearing
Ball
Shaft Length Inches
4.06
Shaft Dia Inches
0.3
Thermal Protection
BR-A1D130
Ambient Deg C
60
Ins. Class
Class B
Capacitor Included
Yes
Capacitor Rating
6/250V
MFG Name | MFG # |
Packard | 622302 |
Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
