Home  >  Motors  >  HVAC  >  Condenser Fan  > 1/3-1/8HP 208-230V 825RPM WIZ

1/3-1/8HP 208-230V 825RPM WIZ

No. of Poles 8 Motor Type PSC Enclosure TEAO HP (Max.) 1/3 Voltage 230 Mounting Belly Band, Extended Clampbolts Speeds 1 Hz 60 Rotation REV Multi-Rated HP 1/8-1/3 RPM Range 825 NEMA Frame Size 48 Phase Single Standards CUL FLA 1.9 Bearing Ball Lead Length (in.) 36 Thermal Protection Auto Ambient Deg C 60 Ins. Class B Shaft Dia. (in.) 1/2 Capacitor Included No Shaft Length (in.) 6.5 Capacitor Rating 10/370 Service Factor 1.0 Duty Continuous
Item #: 10459
1/3-1/8HP 208-230V

Muti-Horsepower Condenser Fan Motor

  • Rheem mounting holes with screws installed
  • Water slinger on shaft
  • A/C or Heat Pump duty
  • Thru bolt or band mounting
  • 36 in. Leads

    • Motors

    No. of Poles
    8
    Motor Type
    PSC
    Enclosure
    TEAO
    HP (Max.)
    1/3
    Voltage
    230
    Mounting
    Belly Band, Extended Clampbolts
    Speeds
    1
    Hz
    60
    Rotation
    REV
    Multi-Rated HP
    1/8-1/3
    RPM Range
    825
    NEMA Frame Size
    48
    Phase
    Single
    Standards
    CUL
    FLA
    1.9
    Bearing
    Ball
    Lead Length (in.)
    36
    Thermal Protection
    Auto
    Ambient Deg C
    60
    Ins. Class
    B
    Shaft Dia. (in.)
    1/2
    Capacitor Included
    No
    Shaft Length (in.)
    6.5
    Capacitor Rating
    10/370
    Service Factor
    1.0
    Duty
    Continuous
    MFG NameMFG #
    Century/AO SmithORM5488B
    EconomasterEM3459
    GE/Genteq3459
    Packard45488B
    US Motors/Emerson5464
    Wagner/DiversitechWG840459

    Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.

    ©MOTORS & ARMATURES, INC.
    MFG NameMFG #
    MARS22459

    Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.

    ©MOTORS & ARMATURES, INC.
