Home
>
Motors
>
HVAC
>
OEM Replacement
> 1/4HP 230V 1550 RPM
1/4HP 230V 1550 RPM
Motor Type
PSC
Enclosure
OAO
H.P. (Max.)
1/4
Voltage
230
Speeds
1
Hz
50/60
Rotation
CW
RPM Range
1550
NEMA Frame Size
48
Phase
Single
Standards
CUL
FLA
2.1
Mount
Thru Bolt/Belly Band Bracket
Bearing
Sleeve
Shaft Length Inches
3
Shaft Dia Inches
1/2
Thermal Protection
Auto
Ambient Deg C
60
Ins. Class
Class B
Capacitor Included
No
Capacitor Rating
5/370
Replaces
050-0238-00, 5KCP39GG357S, 6124, K55BZY1439
Item #:
10264
Motors
Motor Type
PSC
Enclosure
OAO
H.P. (Max.)
1/4
Voltage
230
Speeds
1
Hz
50/60
Rotation
CW
RPM Range
1550
NEMA Frame Size
48
Phase
Single
Standards
CUL
FLA
2.1
Mount
Thru Bolt/Belly Band Bracket
Bearing
Sleeve
Shaft Length Inches
3
Shaft Dia Inches
1/2
Thermal Protection
Auto
Ambient Deg C
60
Ins. Class
Class B
Capacitor Included
No
Capacitor Rating
5/370
Replaces
050-0238-00, 5KCP39GG357S, 6124, K55BZY1439
MFG Name | MFG # |
Copeland | 050-0238-00, 050-0107-01 |
GE/Genteq | 5KCP39GG357S |
US Motors/Emerson | 6124, K55BZY-1439 |
Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
