> 1/20HP 115V 3.3 DIA LARKIN REP
Sleeve Bearing Original OEM-type mounting Original OEM-type wiring Specially selected low temp oil Full flatted oxide shaft
1/20HP 115V 3.3 DIA LARKIN REP
Motor Type
Shaded Pole
Enclosure
Open
H.P. (Max.)
1/20
Voltage
115
Speeds
1
Hz
60
Rotation
CCW
RPM Range
1550
NEMA Frame Size
3.3
Phase
Single
Standards
CSA
FLA
1.9
Mount
Thru Bolt
Bearing
Sleeve
Shaft Length Inches
2.25
Shaft Dia Inches
5/16
Thermal Protection
Auto
Ambient Deg C
40
NOTE
Ripcord 18/2
Ins. Class
Class B
Capacitor Included
No
Item #:
09932
MARS One-On-One™ 3.3" Commercial Refrigeration Evaporator Fan and Blower Motors
Motors
Motor Type
Shaded Pole
Enclosure
Open
H.P. (Max.)
1/20
Voltage
115
Speeds
1
Hz
60
Rotation
CCW
RPM Range
1550
NEMA Frame Size
3.3
Phase
Single
Standards
CSA
FLA
1.9
Mount
Thru Bolt
Bearing
Sleeve
Shaft Length Inches
2.25
Shaft Dia Inches
5/16
Thermal Protection
Auto
Ambient Deg C
40
NOTE
Ripcord 18/2
Ins. Class
Class B
Capacitor Included
No
