Home
>
Motors
>
HVAC
>
Direct Drive
> 1/2HP 208-230V 1075RPM REV ROT
1/2HP 208-230V 1075RPM REV ROT
Motor Type
PSC
Enclosure
Open
H.P. (Max.)
1/2
Voltage
208-230
Speeds
3
Hz
60
Rotation
CW/CCW
RPM Range
1075
NEMA Frame Size
48
Phase
Single
Standards
UL
FLA
4.5
Mount
All Angle
Bearing
Sleeve
Shaft Length Inches
9.82
Shaft Dia Inches
1/2
Thermal Protection
Yes
Ambient Deg C
40
Ins. Class
Class B
Capacitor Included
No
Capacitor Rating
5/370
Item #:
03588
Motors
Motor Type
PSC
Enclosure
Open
H.P. (Max.)
1/2
Voltage
208-230
Speeds
3
Hz
60
Rotation
CW/CCW
RPM Range
1075
NEMA Frame Size
48
Phase
Single
Standards
UL
FLA
4.5
Mount
All Angle
Bearing
Sleeve
Shaft Length Inches
9.82
Shaft Dia Inches
1/2
Thermal Protection
Yes
Ambient Deg C
40
Ins. Class
Class B
Capacitor Included
No
Capacitor Rating
5/370
