Home
>
Motors
>
Refrigeration
>
3.3 Inch
> 3.3 1/12HP 208-230V1500RPM
Motors delivers more power and lower amp draw compared to shaded pole
3.3 1/12HP 208-230V1500RPM
Motor Type
PSC
Enclosure
Open
H.P. (Max.)
1/12
Voltage
208-230
Multi-Rated H.P.
1/12,1/15,1/18
Speeds
1
Hz
50/60
Rotation
CW LE
RPM Range
1550
NEMA Frame Size
3.3 Stud
Phase
Single
Standards
CUL
FLA
0.56
Mount
Thru Bolt
Bearing
Sleeve
Shaft Length Inches
2.55
Shaft Dia Inches
0.315"
Thermal Protection
Auto
Ambient Deg C
60
Ins. Class
Class B
Capacitor Included
Yes
Capacitor Rating
4/370V
Item #:
01125
MARS 3.3" Commercial Refrigeration Multi-Horsepower Motor
Replaces hundreds of OEM shaded pole evaporator fan motors found in Bohn, Nutone, Chandler, Larkin, Kramer, Climate Control, McQuay, Heatcraft and reduce truck stock costs
Motors
Motor Type
PSC
Enclosure
Open
H.P. (Max.)
1/12
Voltage
208-230
Multi-Rated H.P.
1/12,1/15,1/18
Speeds
1
Hz
50/60
Rotation
CW LE
RPM Range
1550
NEMA Frame Size
3.3 Stud
Phase
Single
Standards
CUL
FLA
0.56
Mount
Thru Bolt
Bearing
Sleeve
Shaft Length Inches
2.55
Shaft Dia Inches
0.315"
Thermal Protection
Auto
Ambient Deg C
60
Ins. Class
Class B
Capacitor Included
Yes
Capacitor Rating
4/370V
MFG Name | MFG # |
Century/AO Smith | 9720A |
Fasco | 7190-0442, D1125 |
Packard | 41125 |
US Motors/Emerson | 9656, 8658, 9664 |
Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
