Home  >  Motors  >  HVAC  >  Condenser Fan  > 1/6-1/3 MULTI HP CF

1/6-1/3 MULTI HP CF

Motor Type PSC Enclosure TEAO H.P. (Max.) 1/3 Voltage 208-230 Multi-Rated H.P. 1/6-1/3 Speeds 2 Hz 60 Rotation REV RPM Range 1075 NEMA Frame Size 48 Phase Single Standards CUL FLA 2.6 Mount All Angle Bearing Ball Shaft Length Inches 5 Shaft Dia Inches 1/2 Thermal Protection Auto Ambient Deg C 60 Ins. Class Class B Capacitor Included No Capacitor Rating 5/7.5/370
Item #: 10465
10465

Motors

Motor Type
PSC
Enclosure
TEAO
H.P. (Max.)
1/3
Voltage
208-230
Multi-Rated H.P.
1/6-1/3
Speeds
2
Hz
60
Rotation
REV
RPM Range
1075
NEMA Frame Size
48
Phase
Single
Standards
CUL
FLA
2.6
Mount
All Angle
Bearing
Ball
Shaft Length Inches
5
Shaft Dia Inches
1/2
Thermal Protection
Auto
Ambient Deg C
60
Ins. Class
Class B
Capacitor Included
No
Capacitor Rating
5/7.5/370
MFG NameMFG #
Century/A.O. SmithFE6000
US Motors/Emerson5462
FascoD2827
Genteq/Regal3465
MarathonX072
Nordyne/Partners Choice01-0695
Rheem/Ruud Protech51-23053-21
Carrier/Totaline RCDP257-E5462
Diversitech/WagnerWG840465
York/Source 2S1-FHM3465
ROTOMR22605

Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.

©MOTORS & ARMATURES, INC.

MFG NameMFG #
JARD22465

Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.

©MOTORS & ARMATURES, INC.
