Home
>
Motors
>
Refrigeration
>
3.3 Inch
> 1/20 HP 208/230V 3.3 SUPER FIT
1/20 HP 208/230V 3.3 SUPER FIT
Motor Type
Shaded Pole
Enclosure
Open
H.P. (Max.)
1/20
Voltage
208-230
Speeds
1
Hz
60
Rotation
CW
RPM Range
1550
NEMA Frame Size
3.3
Phase
Single
Standards
CSA
FLA
0.9
Mount
Thru Bolt
Bearing
Sleeve
Shaft Length Inches
2.5
Shaft Dia Inches
5/16
Thermal Protection
Auto
Ambient Deg C
40
Ins. Class
Class B
Capacitor Included
No
Item #:
09927
MARS Super-Fit Commercial Refrigeration Evaporator Fan and Blower Motor
- Replaces virtually all popular 3.3in. dia. Commercial refrigeration evaporator fan motors
- All Angle operation
- Adaptable to front or rear mounting
- Specially selected low temp oil
- Full flatted oxide shaft
Motors
Motor Type
Shaded Pole
Enclosure
Open
H.P. (Max.)
1/20
Voltage
208-230
Speeds
1
Hz
60
Rotation
CW
RPM Range
1550
NEMA Frame Size
3.3
Phase
Single
Standards
CSA
FLA
0.9
Mount
Thru Bolt
Bearing
Sleeve
Shaft Length Inches
2.5
Shaft Dia Inches
5/16
Thermal Protection
Auto
Ambient Deg C
40
Ins. Class
Class B
Capacitor Included
No
| MFG Name | MFG # |
| Century/AO Smith | AO188, AO189 |
| Fasco | D188,D189 |
| Magnetek | 575 |
| RMR | RR-4107 |
Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
