Home  >  Motors  >  Refrigeration  >  3.3 Inch  > 1/20 HP 115V 3.3 SUPER FIT

1/20 HP 115V 3.3 SUPER FIT

Motor Type Shaded Pole Enclosure Open H.P. (Max.) 1/20 Voltage 115 Speeds 1 Hz 60 Rotation CW RPM Range 1550 NEMA Frame Size 3.3 Phase Single Standards CSA FLA 1.7 Mount Thru Bolt Bearing Sleeve Shaft Length Inches 2.5 Shaft Dia Inches 5/16 Thermal Protection Auto Ambient Deg C 40 Ins. Class Class B Capacitor Included No
Item #: 09917
09917

MARS Super-Fit™ 3.3" Commercial Refrigeration Evaporator Fan and Blower Motor

Replaces virtually all popular 3.3" dia. Commercial refrigeration evaporator fan motors

  • All Angle operation
  • Adaptable to front or rear mounting
  • Specially selected low temp oil
  • Full flatted oxide shaft
  • Motors

    Motor Type
    Shaded Pole
    Enclosure
    Open
    H.P. (Max.)
    1/20
    Voltage
    115
    Speeds
    1
    Hz
    60
    Rotation
    CW
    RPM Range
    1550
    NEMA Frame Size
    3.3
    Phase
    Single
    Standards
    CSA
    FLA
    1.7
    Mount
    Thru Bolt
    Bearing
    Sleeve
    Shaft Length Inches
    2.5
    Shaft Dia Inches
    5/16
    Thermal Protection
    Auto
    Ambient Deg C
    40
    Ins. Class
    Class B
    Capacitor Included
    No
    MFG NameMFG #
    Century/AO SmithAO132, AO133
    FascoD132
    Magnetek572, 574, 30, 31
    RMRRR-1107

    Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
